Machine Description
Expresspacks Leak Tester is composed with conveyor, leak tester head and PLC system. It can install maximum 8 leak tester heads. Any defected bottles will be automatically rejected.
-
Feature
-
Machine Parameter
Item
Standard Leak Tester
Note
Model
EPLT-01
Air pressure
0.6±0.1MPa
Air consumption
100L/min filter air
Parameter
Accuracy: hole diameter≥0.3mm
Related to bottle volume
Accuracy>99.9%
Error rate<0.1%
Channel
8
Related to bottle volume and channel qty
External Dimensions
1500(L)X700(W)X1700（H）
Note：Above number is standard products, please contact us for any special request.
Standard Leak Tester
Expresspacks Leak Tester is composed with conveyor, leak tester head and PLC system. It can install maximum 8 leak tester heads. Any defected bottles will be automatically rejected.
